對于單線和雙線的Genius網絡總線來說，Genius總線控制器應該被安放在總線的同一端，就像2-7頁的圖中所示。特殊的，第二單元應被安放在總線的–端，第一單元應該放置在第二單元和Genius設備之間。在總線控制器之間不允許放置VO模塊和其它模板。
