在多點配置中，上位機裝置作為主控裝置進行配置，而一一個或多個PLC作為從屬裝置進行配置。當主控裝置和任何–個從屬裝置之間的最大距離不超過4000英尺(1200米)時，可以采用多點連接法，本圖假設采用質量良好的電纜，并處在中等“噪音”環境中。在“菊花鏈”或多點配置中，采用RS-422最多可以連接8臺從屬裝置。RS-422線路中可以包括信號:交換線路，并且要按照“電纜和連接器規格”一節中的規定選用電線類型.
